AUTEL smart electricity meter, single-phase

Autel Smart Meter 1F AC is a universal electricity meter that is suitable for single-phase electricity networks. The meter is adapted to withstand electric current up to 100 A and is easily mounted on standard DIN rails. It can measure and display 1-phase electric current parameters. Simple and intuitive control, equipped with remote data reading.

Features:

MID Certified (B and D)
100 A single phase input
Four kWh measurment modes for PV and battery storage
Built in Modbus and pulsed outputs or optional Mbus interface
Simple menu navigation
Two module DIN rail mounted
Highly visible backlit display

Displayed parameters:

Phase to Neutral Voltage (V
Phase Current (A
Frequency (Hz
Power Factor ( PF)
Power max demand (MD kW)
Active power (kW)
Reactive power (kVAr)
Apparent power (kVA)
Import active power (kWh)
Export active power (kWh)
Total active power (kWh)
Imprt reactive power (kVAh)
Export reactive power (kVAh)
Total reactive power (kVAh)
Hours Run
