Blackmagic Design HyperDeck Studio HD Pro (HYPERD/ST/DFHP)

Artikuls 643474
Pēc pasūtījuma
Ražotājs
Blackmagic
1 070,00 €
Ikmēneša maksājums no €33.01

HyperDeck Studio HD Pro ietver visas Plus modeļa funkcijas, taču pilna plaukta platumā ir vieta vēl vairāk funkcijām! Lielākajam modelim ir vieta diviem SSD slotiem, taču tajā joprojām ir divi SD karšu sloti, kas ir mazākajiem modeļiem. Tas nozīmē, ka varat acumirklī pārvietot multivides kartes starp dažādiem HyperDeck Studio modeļiem. Jums ir ērtas transportēšanas vadības pogas, kā arī apstrādāta metāla meklēšanas skala ar elektronisko sajūgu rotācijas ierobežošanai atspoles režīmā. Ir arī atsevišķas pogas lēnās kustības, atspoles un ritināšanas meklēšanas skalas režīmiem. Aizmugurējā panelī ir papildu vieta, tāpēc laika koda savienojumi ir uzlaboti uz XLR savienotājiem.



Connections

SDI Video Inputs

1

SDI Video Outputs

2

SDI Monitor Outputs

1

SDI Rates

270Mb, 1.5G, 3G, 6G.

HDMI 2.0 Video Inputs

1

HDMI 2.0 Video Outputs

1

Built in Speaker

Mono

Audio Output

1 x 6.35 mm headphone jack.

Screen

2.2 inch LCD.

Timecode Connections

1 x XLR In, 1 x XLR Out.

Reference Connections

1 x BNC In, 1 x BNC Out.
Tri-Sync or Black Burst.

SDI Audio Inputs

16 channels embedded audio.

SDI Audio Outputs

16 channels embedded audio.

HDMI Audio Inputs

8 channels embedded audio.

HDMI Audio Outputs

8 channels embedded audio.

Remote Control

1 x RS-422 In, 1 x RS-422 Out.

Recorder Configuration

Via user interface orBlackmagic HyperDeck Ethernet Protocol.

Ethernet

1Gb/s

Computer Interface

1 x USB Type-C 3.0 (up to 5Gb/s) forexternal drive recording, webcam out,software configuration and updates.

HyperDeck Studio HD Pro

Standards

SD Video Standards

525i59.94 NTSC, 625i50 PAL

HD Video Standards

720p50, 720p59.94, 720p60
1080i50, 1080i59.94, 1080i60
1080p23.98, 1080p24, 1080p25, 1080p29.97, 1080p30, 1080p50, 1080p59.94, 1080p60
1080PsF23.98, 1080PsF24, 1080PsF25, 1080PsF29.97, 1080PsF30

2K DCI Video Standards

2Kp23.98 DCI, 2Kp24 DCI, 2Kp25 DCI, 2Kp29.97 DCI, 2Kp30 DCI

Ultra HD Video Standards

2160p23.98, 2160p24, 2160p25,2160p29.97, 2160p30

4K DCI Video Standards

4Kp23.98 DCI, 4Kp24 DCI, 4Kp25 DCI, 4Kp29.97 DCI, 4Kp30 DCI

SDI Compliance

SMPTE 259M, SMPTE 292M, SMPTE 296M, SMPTE 424M, SMPTE 425M level A and B, SMPTE 2081‑1, SMPTE 2081‑10,SMPTE 2084 and SMPTE 2108‑1.

SDI Metadata Support

HD RP188 and closed captioning CEA‑708. HDR Metadata supported on SDI.

Supported HDMI Formats

525i59.94 NTSC, 625i50 PAL,
720p50, 720p59.94, 720p60,
1080i50, 1080i59.94, 1080i60,
1080p23.98, 1080p24, 1080p25, 1080p29.97, 1080p30, 1080p50, 1080p59.94, 1080p60,
2Kp23.98 DCI, 2Kp24 DCI, 2Kp25 DCI, 2Kp29.97 DCI, 2Kp30 DCI,
2160p23.98, 2160p24, 2160p25, 2160p29.97, 2160p30,
4Kp23.98 DCI, 4Kp24 DCI, 4Kp25 DCI, 4Kp29.97 DCI, 4Kp30 DCI

Audio Sampling

Television standard 24‑bit, 48 kHz sample rate.

Video Sampling

4:2:2 YUV

Color Precision

10‑bit

Color Space

REC 601, REC 709, REC 2020.33 point 3D LUTS can be applied to SDI monitor out.

HDR Support

Hybrid Log‑Gamma, ST2084 300, ST2084 500, ST2084 800, ST2084 1000, ST2084 2000, ST2084 4000, ST2084.

Multi Rate Support

Auto detection of SD, HD and 6G‑SDI.

Copy Protection

HDMI input is unable to capture from copy protected HDMI sources. Always confirm copyright ownership before capture or distribution of content.

Media

Media Type

SATA-II or SATA-III 2.5 inch solid state media.UHS-I and UHS-II SD cards.

Media Format

Can format media to ExFAT (Windows/Mac)or HFS+ (Mac) file systems.

Supported Codecs

ProRes HQ QuickTime, ProRes 422 QuickTime, ProRes LT QuickTime, ProRes Proxy QuickTime for all formats up to 2160p30. Playback only of ProRes 4444 QuickTime up to 1080p60 with auto routing of fill and key over SDI A and B outputs. DNxHD 220x, DNxHD 220x MXF, DNxHD 145, DNxHD 145 MXF, DNxHD 45, DNxHD 45 MXF for 720p and 1080p HD formats up to 60fps. DNxHR HQX, DNxHR HQX MXF, DNxHR SQ, DNxHR SQ MXF, DNxHR LB, DNxHR LB MXF for 2K DCI and 2160p formats up to 30fps. H.264 SDI 4:2:2 10‑bit, H.264 High 4:2:0 8‑bit, H.264 Medium 4:2:0 8‑bit, H.264 Low 4:2:0 8‑bit for all formats up to 1080p60.

Control

Built in Control Panel

16 buttons for transport and device control with search dial featuring electronic clutch and 2.2 inch color display.

External Control

RS-422 deck control, SDI start/stop, timecode run. Includes Blackmagic HyperDeck Ethernet Protocol. Supports remote FTP file upload.

Software

Software Included

Blackmagic OS
Blackmagic HyperDeck Setup
Internal Software Upgrade
Loaded at system start, or via Blackmagic HyperDeck Setup using USB port.

Operating Systems

Mac icon

Mac 15.0 Sequoia,
Mac 26.0 Tahoe or later.

Windows Icon

Windows 11

Displays

Built in 2.2 inch LCD for video, audio and timecode monitoring and menu settings.

LED bezel indicator lights around SSD media slots and LED indicator lights above the SD media slots.

Power Requirements

Power Supply

1 x Internal 100 - 240V AC 50/60Hz.

1 x 4 pin XLR 12V DC In for external power supplyor battery use.

Power Usage

100 W max.

Accessories

Optional Accessories

HyperDeck Extreme Control

Physical Installation

1 rack unit height.

Physical Specifications

HyperDeck Studio HD Pro

Environmental Specifications

Operating Temperature

0° to 40° C (32°to 104° F)

Storage Temperature

-20° to 60° C (-4° to 140° F)

Relative Humidity

0% to 90% non‑condensing

What's Included

HyperDeck Studio HD Pro

Kopējie parametri

Ražotājs Blackmagic

Svars

Bruto svars (kg) 3

Garantija

Garantija 2 gadi
